outdoor 320*160mm 32*16pixels 3in1 SMD 1/4 scan RGB P10 full color LED module for Advertising media LED Displayoutdoor 320*160mm 32*16pixels 3in1 SMD 1/4 scan RGB P10 full color LED module for Advertising media LED Displayoutdoor 320*160mm 32*16pixels 3in1 SMD 1/4 scan RGB P10 full color LED module for Advertising media LED Displayoutdoor 320*160mm 32*16pixels 3in1 SMD 1/4 scan RGB P10 full color LED module for Advertising media LED Display

outdoor 320*160mm 32*16pixels 3in1 SMD 1/4 scan RGB P10 full color LED module for Advertising media LED Display

96% of buyers enjoyed this product! 112 orders
List price:
Price:
& FREE Shipping
You save:
(%)
Shipping:
Free Shipping

15-50 days (ships out within 7 business days)

1870
Quantity:
  • Free Worldwide Shipping
  • 100% Money Back Guarantee
  • 100% Secure Payments

Product Description

P10 outdoor SMD3535 320×160 1/4S

Item

P10

Chip

Epstar

Chip size

Red 9 mil, Green 12. Blue 12mil

Light type

SMD

Pixel Pitch

10mm

Module Size

320mmX160mm

Module Resolution

32 X 16 (dots)

Density of pixel

10000dots/m2

Pixel configuration

1R1G1B

Red wavelength

625±2nm

Green wavelength

525±2nm

Blue wavelength

470±2nm

Colors

16777216

Best viewing distance

≥10m

viewing angle

120°/90°

Maximum power consumption

 20W

Brightness

6000cd/m2

Gray scale

14bits per color

Color temperature

6500k

Control method

Synchronization or Asynchronization

Driving method

1/4 scanning

Frame frequency

60Hz

Refresh frequency

≥600Hz

Working Voltage

DC5V

IP grade

IP67

MTBF

More than 8000hours

Life Span

80,000hours

IMG_1461_IMG_2828IMG_2823IMG_2758IMG_2761IMG_2763IMG_2764IMG_2846 IMG_2811IMG_2771

IMG_1301IMG_1304IMG_1302IMG_1303IMG_1120IMG_1123
IMG_1107
Seamless splicing  Quick install
IMG_0339IMG_0347
psb (2)IMG_0836
Company Profile

1. With professional technical and development team, we are a direct Factory specialized in led display control card, led display module, power for led display, led display, and other led display accessories etc.

2. With more than 10 years’ experience, modern production and test equipment,perfect enterprise management system,high quality research and management team, high quality led display controller, all above make us become popular supplier.

3.  With our high quality and service our products have been exported to various countries and regions in Southeast Asia, Australia, Europe and America etc.

QQ20151107105707QQ20151107105640LIGHTALLLIGHTALL2

We also supply Flight Case

if you need pls contact us.

IMG_1183

IMG_0811

Shipping by Express

1. We Ship to Worldwide.

2. Items are shipped from China via EMS, UPS, FedEx, DHL, TNT and airmail (with tracking number) etc.

3. Delivery time depends on the courier company ,the destinations, the local customs and other factors; We hope it arrive on time, but this international delivery shipping time will be highly depends on the courier company and local customs, hope you can understand if there are any shipping delay caused by above reasons.

Or by Sea

If you want to deliver the led display board by sea pls tell us, we will quote you the ocean freight.

Reviews (0)

No reviews yet.

Leave a Review

Item Specifics

Brand Name:
 SZLIGHTALL
Model Number:
 P10
Display Function:
 Video
Usage:
 Outdoor
Tube Chip Color:
 Full Color
Pixels:
 10mm
brightness:
 7000
LED Type:
 SMD3535
Module size:
 320 x 160mm
input voltage:
 DC5V
guarantee period:
 3 years
Dots:
 32x16

Packaging Details

Type:
 piece
Weight:
0.5kg (1.10lb.)
Size:
35cm x 5cm x 18cm (13.78in x 1.97in x 7.09in)
